產品描述
開裝封箱一體機/All-in-one machine for opening, loading and sealing boxes
設備工作流程：
物料由連接輸送帶輸送到指定位置等待裝箱,紙箱由開箱機構開箱等待裝箱。通過紙板裝箱機構動作裝入下紙板,通過裝箱機構動作進行裝箱,然后裝入上紙板,裝箱完成后進入封箱機構進行封箱。
Equipment workflow: The materials are transported to the designated position by the connecting conveyer belt to wait for packing, and the cartons are unpacked by the unpacking mechanism to wait for packing. The lower cardboard is loaded through the action of the cardboard packing mechanism, the lower cardboard is loaded through the action of the packing mechanism, then the upper cardboard is loaded, and after the packing is completed, the upper cardboard enters the box sealing mechanism to seal the box.
設備平面布置圖：Equipment layout
連接輸送帶：Connecting conveyor belt
裝箱機構：Packing mechanism
合格證投放：Certificate release
紙箱料倉：Carton bin 紙墊料倉：Paper pad bin
封箱機構：Sealing mechanism
裝紙墊機構：Paper pad mechanism
主要創新點:/ Major innovations:
304不銹鋼機身配合流線型防護門美觀大方。
304 stainless steel body with streamlined protective door is beautiful and elegant.
集成設計全自動裝箱一體機。
Integrated design of fully automatic packing machine.
模塊化理念適用范圍廣。
The concept of modularization has a wide range of applications.
紙板投放倉不停機擺放紙板。
The cardboard placing bin does not stop to place cardboard.
開箱機構采用伺服擺臂結構。
The unpacking mechanism adopts a servo swing arm structure.
紙板投放采用獨立機械手。
Independent manipulator is used for cardboard delivery.
配有各種監測裝置,保證安全穩定。
Equipped with various monitoring devices to ensure safety and stability.
主要技術參數/ Main technical parameters
小于400(箱/小時)/ Less than 400 (boxes/hour)
生產能力/ Production capacity
雙機械手各12(次/分鐘)/ Two manipulators each 12 (times/minute)
機械手抓取生產能力/ Manipulator grab production capacity
膠帶封箱或者熱熔膠封箱/ Tape sealing box or hot melt adhesive sealing box
封箱方式/ Sealing method
最小值300X250X200mm/ Minimum 300X250X200mm
紙箱尺寸/ Carton size
最大值/ Maximum value
600X500X500mm/ 600X500X500mm
電源:AC380/50Hz耗電量:7.5kw/ Power Supply: AC380/50Hz Power Consumption: 7.5kw
電源/ Power supply
壓力:0.6MPa耗氣量:小于1立方米/小時/ Pressure: 0.6MPa air consumption: less than 1 cubic meter/hour
氣源/ air supply
外形尺寸(長×寬x高）/ Overall dimensions (length x width x height)
5000*2000*2900mm/ 5000*2000*2900mm
3000(kg)/ 3000(kg)
重量/ Weight
鋁合金、304不銹鋼/ Aluminum alloy, 304 stainless steel
主要材質/ Main material
▲機器可能在未事先通知的情況下對技術進行改進,照片僅供參考,以實物為準。
▲ The machine may improve the technology without prior notice. The photos are for reference only and subject to the actual objects.
